Walkthrough of Deploying & Configuring VCF Identity Broker 9.0.2 with Active Directory LDAPS

sargonkhizeran

I will be running through Installing & Configuring VCF Identity Broker 9.0.2. I will be configuring this with my internal Active Directory instance. You can read more about it by visiting Broadcom TechDocs; Deploying VCF Identity Broker.

From the VCF Operations console >> Fleet Management >> Lifecycle >> VCF Management. Locate ‘Components’ >> ‘Add Components’ and select ‘identity broker’

I have already downloaded the download necessary from Binary Management.

I created a certificate previously; this will require providing FQDN and IP addresses for appliances. I’m using a single certificate for multiple products.

I will be electing to use a pre-defined NTP and DNS server from the initial deployment of VCF Operations

I have a DNS record of vcf-vidb.khizeran.com that I plan on using as the VIP.

Providing a range of IPs to be used for appliances in a cluster

Successfully completed

Once completed, navigate to Fleet Management >> Identity & Access

Review the Prerequisites, check and click ‘Continue’

Select the VCF Instance from the drop-down

The following step would usually be the first stop, I went right into the installation first, however the configuratin will recognize the deployed solution.

You can view the options available, for my lab it will be AD/LDAP

For this next step, I have a Microsoft CA in my homelab and I create a file in a *.pem format containing my AD cert for LDAPS.

Open using an editor such as Notepad++ and Save the certificate as a *.pem file.

Uploaded my cert and have all of the following selected.

For the final step we will further configure directory integration with permissions to pull in

One of the last but not least steps is configuring components, these are the various solutions part of VCF

From the following screen, we can click on Component Configuration

You will find that vCenter has been integrated, however further permission assignments will be needed within vCenter.

This blog was already long enough, I will consider creating additional for other component configurations.

Home Lab, VCF

Mitigating Rising Memory Costs with NVMe Memory Tiering in ESXi 9.0.2

sargonkhizeran

I will be following a Broadcom article (Memory Tiering Configuration) to enable Memory Tiering.

These hosts have not been commissioned into VCF yet, the plan will be prep these as a vSAN cluster.

This is on a SuperMicro E300-9D-8CN8TP and the NVME storage is Samsung 990 PRO 1TB.

Here you can see the amount of physical memory, it’s 128GB

Here is a breakdown of the storage on the host

With a SSH session, place the host in Maintenance Mode

esxcli system maintenanceMode set --enable true

List the NVMe devices on the host

esxcli storage core adapter device list

Copy the full Device UID

Run the following command to create

esxcli system tierdevice create -d /vmfs/devices/disks/<Device UID>

Tun the following command to check the device being claimed by tiering

esxcli system tierdevice list

The next step will be to enable Memory Tiering on the ESX host itself. Because these hosts are managed as standalone, I can go into Advanced Settings and enable it from there.

Filter for ‘tiering’ and you will find other options but the one we want is ‘ VMkernal.Boot.memoryTiering ‘

Highlight, Edit Option, set to True and Save. Reboot the host.

Once the host comes back, we now have a 1:1 ratio of DRAM to NVMe tiering. This can be modified up to 4:1

Set your percentage in ESXi Advanced Host setting ‘ Mem.TierNvmePct ‘ Default value is ‘100’. e.g. If you have 128GB of DRAM and set the value to 200 it would give you 384GB of RAM (256 would be from Tiering)

The document in the beginning of the article has a lot of great information on the various Memory Tiering settings.

Another helpful article I came across is from Lenovo
Implementing Memory Tiering over NVMe using VMware ESXi 9.0 > Lenovo Press

Home Lab, Networking, VCF

Configuring Centralized Connectivity Networking with BGP in VCF 9.0

sargonkhizeran

VCF 9.0 introduced a new way to setup and configuring networking. The two models that can be configured depending on your business’s needs. There is Centralized Connectivity & Distributed Connectivity. Not going into full detail with the difference of those two, please read about it here, Setting up Network Connectivity.

Some of the plumbing of the network, it’s all Ubiquiti Unifi system, ESX hosts have dual 10GB interfaces each. My choice of routing is BGP, read more about my experience here; BGP Peering NSX Tier-0 with Ubiquiti UDM Pro. This will be key as I want my virtual networking to traverse the physical (North/South)

My blog on BGP Peering is pending an update. I will work on an update, however should get the peering to work.

Deployment

From the vSphere client, highlight the vCenter instance, in the right pane navigate to Networks >> Network Connectivity.

You will be presented with a Gateway Type, ours will be Centralized Connectivity

Networking Prerequisites

This is where we configure our Edges, select our size and give a unique name for our Edge cluster object.

Clicking ‘Add’ will bring up configuration for the first Edge node. In this section it will be mainly management configuration for the Edge as well as Edge TEPs.

The bottom was cut off, here is the remainder

Once we save, we have an option of Adding or Cloning the configuration.

Fill out the unique settings for the clone

There is an option to have passwords auto generate or you can specify ‘admin’ & ‘root’ passwords.

Example of filling it out

The final step before Deploying will be the ‘Workload Domain Connectivity’, this will contain BGP related configuration and Edge gateway uplink configuration.

The next series of screenshots are configuring 2 Gateway uplinks for each edge appliance.

I have 2 physical networks created (vlan 3 & vlan4) as interfaces specifically for overlay and North-South communication.

The final step is Deploy. Take a look at some of the photos post-install.

The final step is to perform an Inventory Sync in VCF Operations. This let’s Operations manage monitoring and password Lifecycle.

Under Fleet Management >> Passwords, Edge appliances are not there.

From VCF Operations >> Inventory, select the Management Domain and perform a Sync Inventory

After some time, the additional accounts will appear under Fleet Management/Passwords
